    Yamaha LC 135- Auto Clutch

    • Front telescopic forks
    • Rear monocross absorbers
    • Electric and kick start

    *Subject to price changes *Subject to stock and color availability *Free delivery within KL/Selangor Area

    RM8,300.00
    i h
    shipping.estimateshippingpopup.shiptotitle
    *
    *
    shipping.estimateshippingpopup.chooseshippingtitle
    shipping.estimateshippingpopup.shippingoption.name
    shipping.estimateshippingpopup.shippingoption.estimateddelivery
    shipping.estimateshippingpopup.shippingoption.price
    shipping.estimateshippingpopup.noshippingoptions

    COVER HORN

    Even steady, even aggresive! Elegant and stunning cover design produces a clearer sound!

    AIR SCOOP

    A pair of air scoop (left and right) refines the flow of air, allowing the motorcycle to be more aerodynamic and stylish.

    FRONT COVER UNDER

    The front cover under are designed to protect the engine and providing an impressive appearance.

    Specification

    Engine

    Cylinders Single Cylinder
    Displacement 134 cm3
    Bore x Stroke 54.0 X 58.7 mm
    Compression Ratio 10.9 : 1
    Maximum Horsepower 8.93kW (8,500rpm)
    Maximum Torque 11.79N.m (5,500rpm)
    Starting System Electric and Kick
    Lubrication SystemWet Sump
    Engine Oil Capacity 0.9 litres
    Fuel Tank Capacity 4.0 litres
    Carburetor BS25 x 1
    Ignition System DC – CDI
    Headlight 12v, 35W/35W

    Chasis

    Frame Type Diamond
    Overall Length 1,960 mm
    Overall Width 695 mm
    Frame Type Diamond
    Seat Height 775 mm
    Minimum Ground Clearance130 mm
    Dry Weight105 kg

    Transmission

    Transmission TypeRotary Type 4-Speed
    Primary Reduction Ratio2.875
    Secondary Reduction Ratio 2.600
    Gear Ratios1st: 2.833; 2nd: 1.875; 3rd: 1.353; 4th: 1.045
    Clutch Type Automatic Centrifugal / Constant Mesh, Wet Multi – Plate

    Brakes

    Front and Rear Hydraulic Single Disc and Drum

    width: 20%; min-width: 200px;

    Suspension

    Front Suspension TypeTelescopic
    Rear Suspension TypeMonocross

    Engine

    Front Tyre70/90 – 17
    Rear Tyre80/90 – 17
